Brand : HEIDENHAIN
ROC 1013
-
ROC 1013 absolute rotary singleturn encoder with integral bearing for separate shaft coupling, with a 4mm diameter shaft with EnDat2.2 interface and 1Vpp incremental signals.
- Request A Quote
Description
HEIDENHAIN ROC 1013 absolute singleturn encoder with a 4mm diameter shaft with an accuracy as low as ±60"
ROC 1013 absolute singleturn encoder
- Positions per revolution: 8192
- Data interface: EnDat01
- Output code: Binary
- Line count: 512
- Output signal: ~1Vpp
- Cutoff frequency (-3 dB): 190.00 kHz
- Power supply: 3.6 V ... 14 V
- Flange version: Synchro flange Ø 36.5mm, centering collar 33mm, bolt circle Ø 26mm, 4 x M3
- Shaft: solid shaft, diameter 4 mm, length 12.5 mm
- Degree of protection: IP64 (EN60529)
- Operating temperature: -10/+100 °C
- Electrical connection: Coupling M23, male, 17-pin
